If you want a circuit board printer you can trust, the Voltera V-One is a great choice in 2025. This printer can print, drill, put on solder paste, and heat parts all in one small machine. You should see if this printer works for you by thinking about how fast you need to make things, the size of your boards, and how many things you want it to do. Think about what you want—if you are a hobbyist, a new business, or in school—before you pick a circuit board printer. The best printer will help you work better and make good prototypes.
Key Takeaways
Pick a circuit board printer that fits your project needs. Think about speed, board size, and features for the best results.
The Voltera V-One is fast and can do many things. It is good for hobbyists, teachers, and new companies who want easy prototyping.
Expensive printers like the Nano Dimension DragonFly can print many layers. They are very precise and made for professional labs.
Make sure the printer works with your favorite PCB design software. This will help you save time and make fewer mistakes.
Think about your budget, the features you want, and upgrade choices. Pick a printer that can grow with your PCB projects.
Comparison Table
Key Specs
When you look at desktop circuit board printers in 2025, focus on what matters for your project. Here are the main things you should check:
Printing speed and resolution help you make pcb prototypes fast and with good detail.
Material compatibility lets you use different pcb types, like flexible or multilayer boards.
Some printers can do extra jobs like 3D printing or checking your work as you go, which makes things easier.
Automation and IoT features help your printer work smarter and are simple to control.
Small size and high precision are good if you do not have much space or need very detailed pcb layouts.
Working with pcb design software makes it easy to move your layout to a real pcb.
Here is a table that shows how the top desktop printers for pcb projects in 2025 compare:
Printer Model | Print Speed | Resolution | Board Size Max | Material Support | Multilayer | 3D/Inspection | Software Integration | Automation/IoT | Size |
|---|---|---|---|---|---|---|---|---|---|
Voltera V-One | Fast | High | 138×102 mm | FR4, Flex | 2 layers | No | pcb design software | Partial | Compact |
Nano Dimension DragonFly | Very Fast | Ultra High | 200×200 mm | FR4, Flex, Others | 10+ layers | Yes | pcb design software | Full | Desktop |
LPKF ProtoMat Series | Fast | High | 229×305 mm | FR4, Aluminum | 8 layers | No | pcb design software | Partial | Medium |
BotFactory SV2 | Moderate | High | 150×150 mm | FR4, Flex | 4 layers | Yes | pcb design software | Partial | Compact |
Tip: Make sure your printer works with your favorite pcb design software and layout tools. This will help you save time and make fewer mistakes when you turn your digital layout into a real pcb.
Best-Use Scenarios
You need to pick the right printer for your needs. Here are some common situations:
If you want to make prototypes quickly and use pcb design software easily, the Voltera V-One is a good choice.
For advanced research or if you need many layers, the Nano Dimension DragonFly gives you more options and features.
If you teach or learn about pcb layout, the LPKF ProtoMat Series is flexible and has good support.
For new businesses or small labs that want both flexibility and some automation, the BotFactory SV2 is a good balance of price and features.
Always think about your layout needs, the size of your pcb, and how much automation you want. The right printer will help you make working boards faster and with fewer errors.
How to Choose a Circuit Board Printer
Key Factors
When you pick a circuit board printer, focus on what is important for your projects. Print quality is the most important thing. You want a printer that makes sharp lines and clear details on every pcb. The best 3d printer for quality uses special imaging, like laser direct imaging, to give you high precision. This helps you make small lines and tiny parts easily.
Speed is also important. If you need things done fast, find a printer with automated drilling and quick lamination. Some printers can finish a pcb in one day. This helps you work faster and keeps your projects moving.
The size of boards and what materials you can use matter too. The best 3d printer for accuracy lets you use many materials, like FR-4, high Tg FR-4, polyimide, Teflon, and metal core pcbs. Each material acts differently with heat and electricity. For example, FR-4 is good for most projects. Polyimide works well with high heat. Teflon is best for high-frequency circuits. You can see the differences in the table below:
Material Type | Thermal Properties (Tg °C) | Electrical Characteristics (Dielectric Constant & Loss Tangent) | Typical Applications | Cost Level |
|---|---|---|---|---|
FR-4 | Dielectric Constant: 4.2-4.8, Loss Tangent: 0.02 | General-purpose PCBs | Low | |
High Tg FR-4 | 170+ | Dielectric Constant: 4.2-4.8, Loss Tangent: 0.02 | High-temperature circuits | Medium |
Polyimide | 250+ | Dielectric Constant: 3.2-3.5, Loss Tangent: 0.002 | High-reliability, high-temp applications | High |
Teflon (PTFE) | N/A | Dielectric Constant: 2.1-2.6, Loss Tangent: 0.0002 | High frequency, RF applications | Very High |
Metal Core PCBs | N/A | Used for thermal management with metal heat sinks | Thermal-critical applications | Medium-High |
You should also look at software compatibility. The best pcb design software and top pcb design software help you move your layout from the pcb layout editor to the printer. Pick printers that work with popular pcb design software, even free pcb design software, so you can use your favorite tools.
Price and support are important too. You want a printer that fits your budget and has good customer service. Some printers have extra features like 3d printing, inspection, and automation. These can help you get better quality and accuracy, especially if you need high precision or want to try new designs.
Tip: Always check if your printer supports the best 3d printer for quality and the best 3d printer for accuracy. This helps your pcb projects meet your needs for quality and precision.
Matching Features to Needs
You need to match each circuit board printer’s features to what you need. Different people want different things. Here is how you can choose:
Hobbyists: You want a printer that is simple, small, and not expensive. The V-One is great because it can print, drill, put on solder paste, and heat parts all in one. You can use pcb design software like CircuitMaker or EasyEDA for easy layouts. The best 3d printer for quality gives you sharp results, even on small boards.
Startups: You need to make prototypes fast and get feedback quickly. The V-One is fast and keeps your ideas safe by letting you print at your own place. Use the best pcb design software to make your designs faster and more accurate. Automation and 3d printing features help you test new ideas quickly.
Professional Labs: You need high precision, advanced features, and support for multilayer pcbs. The best 3d printer for accuracy and quality lets you make complex layouts easily. Pick printers that work with top pcb design software and give high performance. Look for printers that let you use many materials and board sizes.
Education: You want a printer that is safe, easy to use, and good for students. The V-One is simple to use and helps students learn by doing. You can use free pcb design software or tools like Fritzing and EasyEDA for class projects. High precision and quality help students see their work clearly.
User Type | Printer Model | Key Features | Suitability Reason |
|---|---|---|---|
Hobbyist | V-One | 4-in-1: printing, drilling, solder paste, reflow | Easy for all skill levels; desktop size; fast prototyping |
Startup | V-One | Fast, low-volume prototyping; IP protection | Quick design feedback; protects intellectual property |
Professional Lab | V-One | High precision; multi-function; two-layer PCBs | Engineers need rapid prototyping and assembly |
Education | V-One | Intuitive; hands-on learning; student-friendly | Designed for classroom use and skill development |
You should always think about print quality, accuracy, and precision when picking a printer. The best pcb design software and pcb layout editor help you get the most from your printer. If you want extra features like 3d printing or automation, check if your printer has them. The best 3d printer for quality and the best 3d printer for accuracy will help you get great results, no matter your skill level.
Note: Picking the right printer and software for your needs helps you get the best quality and performance for every pcb project.
Printer Reviews
Voltera V-One
If you want to make a circuit board easily, the Voltera V-One is a good pick. This printer does four jobs in one machine. You can print lines, drill holes, put on solder paste, and heat parts right at your desk. It works with double-sided boards and has a print area of 4.5 by 5 inches. The heater can reach up to 240°C, which is hot enough for most parts. The V-One uses direct-write technology, so you can change your design fast and use different materials.
Feature / Specification | Details |
|---|---|
Device Type | 4-in-1 desktop PCB prototyping tool (circuit printing, drilling, solder paste dispensing, built-in reflow) |
Print Area | 4.5” x 5” |
PCB Type Support | Double-sided PCBs |
Maximum Reflow Temperature | 240°C |
Heater Power | 550 W |
Pin Pitch | Down to 0.5 mm |
Drilling Capability | Drill holes for through-hole components and vias (drill sold separately) |
Solder Paste Dispensing | Stencil-free, automatic dispensing with selective correction |
Reflow Duration | Up to 60 minutes |
Software Compatibility | Universal Gerber file compatibility |
User Interface Features | In-app help videos, live chat, automatic software updates |
Additional Hardware Features | Magnetic tool mounting, limit switches, status LEDs |
Intellectual Property Benefit | Keeps prototyping in-house to protect IP |
Typical Print Time | Under 1 hour |
Main Features:
You can print, drill, add solder paste, and heat parts.
Direct-write 3d printing lets you change things quickly.
It works with pcb design software that uses Gerber files.
You get help from videos and live chat in the app.
Pros:
You can finish a prototype in less than an hour.
Your designs stay safe because you work at your own place.
The printer works with many board types and designs.
You get good quality and can test ideas easily.
Cons:
The printer and supplies cost more than basic ones.
Conductive ink does not work as well as copper for electricity.
You cannot make very tiny or crowded designs.
The process can be slow and needs you to watch it.
The boards do not have solder mask or silkscreen layers.
Note: The Voltera V-One is best for quick, simple boards in labs, schools, or new businesses. If you need super fine details or lots of boards, you might need a different printer.
Ideal User:
The V-One is great for hobbyists, teachers, or engineers who want to make boards fast and keep control. You can use any pcb design software or pcb layout editor that makes Gerber files.
Pricing/Availability:
You can buy the Voltera V-One from the company or sellers. It costs more than starter printers, but you get more features and can do more jobs.
Nano Dimension DragonFly
If you need a printer for professional, multilayer boards, the Nano Dimension DragonFly is a top choice. This printer uses inkjet technology and special nano-particle inks. You can make complex boards with many layers, hidden holes, and plated holes. The DragonFly IV model gives you better resolution, a bigger print area, and more automation than older models.
Feature | DragonFly 2020 Pro | DragonFly IV |
|---|---|---|
Printing Technology | Inkjet deposition | Advanced inkjet deposition |
Materials | Proprietary inks | Enhanced, stable inks |
Resolution | High precision | Even higher, for finer features |
Build Volume | Desktop size | Larger, for bigger boards |
Automation | Manual operation | Increased automation |
Software | Basic design import | Advanced analysis and monitoring |
Precision | Standard for multilayer | Enhanced for complex boards |
Throughput | Lower | Higher, with faster print speeds |
Main Features:
High precision 3d printing with advanced inkjet technology.
You can make full multilayer boards, even with hidden holes.
The printer uses special inks for complex designs.
The software helps you check your design and watch the process.
More automation makes it easier to handle materials.
Pros:
You can make professional multilayer boards in just a few days.
Your secret designs stay safe because you print them yourself.
The printer lets you test ideas and make tricky layouts.
You get high quality and accuracy for research and development.
Cons:
This printer costs much more than other desktop printers.
You must use the company’s special inks and materials.
It is best for labs, not for simple projects.
It can be hard to learn because of all the features.
Tip: If you want the best 3d printer for quality and accuracy, the DragonFly IV is a strong pick for high precision and advanced options.
Ideal User:
This printer is best for people in research, advanced testing, or those who need to keep their ideas safe. The DragonFly works with the best pcb design software and can handle complex, multilayer boards.
Pricing/Availability:
You can get the DragonFly from Nano Dimension’s sales team. The price is high because it has many advanced features and is made for professionals.
LPKF ProtoMat Series
If you want a printer that uses milling for high accuracy, the LPKF ProtoMat Series is a good choice. Models like the S104 have a fast spindle and can change tools by themselves. You can mill and drill up to 8-layer boards, engrave panels, and cut plastic or aluminum. The ProtoMat is great for labs and schools where you need to make many types of projects.
Application | E44 | S64 | S104 |
|---|---|---|---|
Milling/drilling 1- & 2-sided PCBs | Yes | Yes | Yes |
Milling/drilling RF and microwave substrates | No | Yes | Yes |
Milling/drilling multilayers up to 8 layers | Yes | Yes | Yes |
Routing of PCBs | Yes | Yes | Yes |
Engraving front panels/signs | No | No | Yes |
Milling cut-outs in front panels | Yes | Yes | Yes |
Milling SMD solder paste stencils | No | Yes | Yes |
Machining housings | No | Yes | Yes |
Milling solder frames | No | Yes | Yes |
Depaneling and reworking PCBs | No | Yes | Yes |
Drilling test adapters | No | Yes | Yes |
Inspection templates | No | Yes | Yes |
Dispensing | No | Yes | Yes |
Main Features:
The spindle spins up to 100,000 times per minute for fast milling.
It changes tools by itself, so you do not have to.
Sensors check the depth for accurate milling.
The granite base keeps the machine steady and precise.
The software is easy to use and works well for special boards.
You can add a solder paste dispenser for 3d printing stencils.
Pros:
You can make multilayer boards with high accuracy.
The printer works with many materials and jobs.
You get the same good results every time for small batches.
It works with popular pcb design software.
Cons:
This printer is bigger and costs more than simple ones.
Milling makes dust and noise, so you need a good space.
You have to change tools and take care of the machine.
It takes time to learn the advanced features.
Note: The LPKF ProtoMat Series is best if you need high accuracy, many features, and want to use it for teaching or research.
Ideal User:
This printer is great for engineers, researchers, or teachers who want fast, high-quality boards and extra features. The ProtoMat works with the best pcb design software and can handle tough layouts.
Pricing/Availability:
You can buy the ProtoMat Series from LPKF or sellers. The price depends on the model and features, showing it is made for professionals.
BotFactory SV2
If you want a small printer that does many jobs, the BotFactory SV2 is a smart pick. This printer can 3d print, place parts, and put on solder paste in one device. You can use Gerber files from any pcb design software, even KiCAD EDA. You can also upload pictures. The SV2 has its own software, so you can set everything up offline and control how it prints.
Main Features:
It can 3d print both conductive and non-conductive layers, add solder paste, and place parts.
It works with small surface-mount parts down to 0603 size and 0.4 mm pitch.
You can use any pcb design software that makes Gerber files.
The software is built-in, so you control everything in one place.
You can go from design to finished board in one smooth process.
Pros:
You can make prototypes much faster, sometimes in just hours.
The printer can make multi-layer boards and use many parts.
It is small and fits on a desk.
The SV2 works with the best pcb design software and pcb layout editor.
Cons:
It cannot handle very tiny parts like 0402 or 0201.
There is no drill head for through-hole parts.
It is not good for the newest or most crowded designs.
It works best for medium-level projects.
Aspect | Details |
|---|---|
Beneficial Users | Academic researchers, R&D labs, companies needing rapid prototyping |
Supported Components | Surface-mount devices down to 0603, 0.4 mm pitch pins |
Main Limitations | No support for 0402/0201, no drill head, not for BGAs |
Intended Use | Medium-technology prototyping, fast iteration, not for advanced tech |
Tip: The BotFactory SV2 is a good choice if you want a flexible printer that can make and assemble boards quickly.
Ideal User:
The SV2 is best for researchers, lab workers, or companies that need fast, medium-complexity boards. It works with any pcb design software and fits many types of projects.
Pricing/Availability:
You can order the SV2 from BotFactory or partners. The price is fair for what it does, making it a good deal for labs and small businesses.
Alternatives and Considerations
Budget Options
You might want a printer that does not cost too much. Some printers in 2025 are good for saving money and still work well for pcb projects. Sovol has many printers that use flexible filaments and open-source firmware. They are easy to put together. These printers let you start making pcbs without spending a lot.
Model | Price Range (USD) | Key Features |
|---|---|---|
Sovol SV06 Plus | $179 – $299 | Open-source, linear rail, direct drive extruder, flexible filament support |
Sovol SV08 | $519 – $599 | Large build volume, fast speeds, easy assembly, open-source |
Sovol SV08 Max | $1,099 – $1,299 | Extra-large build, professional design, fast assembly |
Sovol Zero | $399 – $499 | Direct drive, flexible filament support, budget-friendly |
Sovol SV07 | $169 – $289 | Beginner-friendly, open-source, direct drive |
Comgrow T500 | N/A | Auto-leveling, very large build volume, direct drive |
Tip: Sovol printers have cool features but do not cost a lot. This makes them a smart pick if you want to save money on pcb printing.
High-End Choices
If you need the best printer for hard pcb jobs, high-end models are for you. These printers are expensive but work fast and are very accurate. They are made for labs and big companies. You get quick part placement, special cameras, and software that helps you manage your work.
Aspect | Details |
|---|---|
Average Cost (2025) | |
Placement Speed | 15,000+ components per hour |
Feeder Capacity | 120+ feeders |
Vision System | Multi-camera for precise alignment |
Software Integration | MES/ERP for automation and management |
SMT Line Cost | $305,000 to $1,220,000 (full production line) |
Advanced Capabilities | High-speed, accurate, automated operation |
Note: High-end printers are best if you need to make lots of pcbs, want perfect results, and need everything to run by itself.
Upgradability
You might want a printer that can change as you need more. Some printers, like the EKRA SERIO and DEK NeoHorizon, let you add new parts and update software. You can make your printer do more as your pcb projects get harder.
Ways to upgrade desktop printers include:
Print audits help you see how much you print and spend.
You can swap old parts for new, energy-saving ones.
Add print management software for better control.
Make your printer safer with encryption and passwords.
Use cloud and mobile printing for more ways to print.
Leasing lets you pay over time instead of all at once.
These upgrades help you save money, keep your printer safe, and help the environment. You also get more work done and your printer will be ready for new pcb jobs.
Callout: Picking a printer you can upgrade means it will still be useful as your pcb needs grow.
The Voltera V-One is a great printer for most people in 2025. It is fast and flexible, so you can make boards quickly. You can use it at your own place for better control. This helps you get good results every time. If you do not have much money or want more features, look at other choices. PCB 3D printing services or the Nano Dimension DragonFly are good options. Always use EDA tools to compare printers for quality and fit. Think about what your project needs. Then pick the printer that gives you the best mix of quality, speed, and price.
FAQ
What is the best way to maintain your circuit board printer?
You should clean your printer after each use. Check for dust or leftover materials. Update the software when new versions come out. Regular care helps your printer last longer and work better.
Can you use any PCB design software with these printers?
Most printers support popular PCB design software that exports Gerber files. Always check the printer’s compatibility list before you start your project. This step helps you avoid errors and wasted time.
How do you choose the right printer for a classroom?
Pick a printer that is safe, easy to use, and has clear instructions. Look for models with built-in help features. A simple setup lets students learn faster and keeps the classroom organized.
Is it possible to upgrade your printer as your needs grow?
Some printers let you add new parts or update software. You can improve speed, safety, or features. Upgrading helps your printer stay useful for new projects and changing technology.
See Also
Key Guidelines To Pick The Perfect Main PCBA
Crucial Advice For Selecting The Ideal PCBA Board
Steps To Choose The Best Fusion PCBA Service
